High Frequency Power Supply Transformer EFD15 High Voltage EFD Ferrite Core PCB Mounting Transformer
Feature:
1. Custom designs available
2. High efficiency of over 95%
3. High frequency range 10kHz-1MHz
4. High isolation strength
5. Lower profile and weight
Application:
1. VCRS, Copy machine , Audio equipment , Game machines
2. TV sets, Microcomputer equipment, printers, Terminals
3. communications control equipment
4.Switching power supply, chargers, alarm system
5. UPS, VCD/DVD players, audio and visual equipment
6. OA machines, inverters, chargers, alarm system
| Specifications | EFD15 transformer |
| Product material | Magnetic core/Bakelite frame/enamelled copper wire |
| Product name | EFD15 |
| Brand name | Fullstar |
| Model Number | EFD TYPE |
| Usage | High Frequency |
| Coil Structure | Toroidal |
| Phase | Single |
| Material | core, wire, bobbin |
| Certification | ISO9001:2008 |
| Package | Carton |
| Shipping Term | DHL Fedex TNT EMS UPS |
| Product features | 1.High efficiency, high quality materials |
| 2.Low working temperature and long service life. |
| 3.Good insulation and high resistance to electric power. |
| 4.Good anti-interference performance and high reliability. |
| 5. Low energy consumption and high dc superposition. |
High frequency transformer -Suitable for AC/DC inverter or DC/AC converter. Customized designs are welcome.
High frequency switching power transformer type we produce: PQ/ EI/ EE/ EF/ ERL/ ETD/ EFD/ RM and other customized.
PQ Series: PQ2020, PQ2016, PQ2625, PQ3230, PQ3535, PQ4040 and PQ5050.
EI series: EI19, EI28, EI33, EI40.
EE series : EE5.0, EE8.3, EE10, EE13, EE16, EE19, EE22, EE25, EE28, EE30, EE33, EE35, EE40, EE42, EE50,EE55,.EE65,EE70.
EF series: EF16, EF20, EF25 and EF32.
ERL series: ERL-28, ERL-35, ERL-39, ERL-42 and ERL-49.
ETD series: ETD29, ETD34, ETD39, ETD44, ETD49, ETD54 and ETD59.
EFD series: EFD15, EFD20, EFD25 and EFD30.
RM series: RM-4, RM-5, RM-6, RM-8, RM-10, RM-12 and RM-14.
